Home MPC153-834

MPC153-834

24″ FHD TFT Medical Grade Panel Computer with 4th Gen Intel® Core™ i7/i5/i3, Celeron® & Pentium® Mobile Processor



Features

  • 15.6″ WXGA TFT LCD display with LED backlight
  • Projected capacitive touch or 5-wire flat resistive touch for optional
  • Fanless design with Intel® Celeron® processor J1900 (up to 2.42 GHz)
  • EN 60601-1/CE/FCC class B certified
  • Half-slim SSD & CFast™ or mSATA
  • Antimicrobial plastic enclosure
  • IP65 front bezel and IPX1 full enclosure design
  • Supports optional wall mount/VESA arm/desktop stand
  • Supports optional smart card reader

Introduction

The new MPC153-834 is equipped with a 15.6-inch WXGA TFT LCD display with high brightness of 300nits. Specifically designed for the medical environment, the medical panel PC has IPX1 compliant chassis and IP65/NEMA 4 rated spill and dust-resistant front panel. Moreover, the wide-screen medical touch panel PC is equipped with an isolated COM port to protect equipment from electrical surges and transient voltage spike. Powered by quad-core Intel® Celeron® processor J1900 (codename: Bay Trail), the powerful 15.6-inch MPC153-834 is an ideal choice as a point-of-patient-care EMR computer, enabling health care professionals to access patient records whenever and wherever needed.

Specifications

LCD Panel
  • 15.6″ WXGA TFT
  • 300 nits
  • 1366 x 768 pixels
CPU
  • Intel® Celeron® processor J1900 up to 2.42 GHz
Chipset
  • SoC integrated
System Memory
  • 1 x 204-pin SO-DIMM DDR3L-1066/1333, up to 8 GB
BIOS
  • AMI
COM
  • 2 x RS-232/422/485
  • 1 x isolated RS-232
USB
  • 2 x USB 3.0
Ethernet
  • 2 x 10/100/1000 Mbps (Intel® i210IT)
Display
  • N/A
Audio
  • Line-out
Camera
  • N/A
Optical Drive
  • N/A
Storage
  • 1 x Half-slim SSD
  • 1 x CFast™ or mSATA
Expansion
  • 1 x Full-size PCI Express Mini Card with mSATA supported
  • 1 x Full-size PCI Express Mini Card with SIM slot
Others
  • Smart card reader
Touchscreen
  • Projected capacitive multi-touch or 5-wire flat resistive touch
Front Bezel
  • IP65 front bezel
Power Consumption
  • N/A
Power Supply
  • AC version: medical grade 100-240V AC-DC, 60W power adapter
  • DC version: 9~36VDC with terminal block
Watchdog Timer
  • 255 levels, 0 ~ 255 sec.
Operating Temperature
  • 0°C ~ +40°C (32°F ~ +104°F) w/RAM thermal kit)
Relative Humidity
  • 20% ~ 90% @ 40°C; non-condensing
Dimensions
(W x D x H)
  • 394.2 x 57 x 257.2 mm (15.53″ x 2.25″ x 10.13″)
Weight (net/gross)
  • 3.0 kg (6.61 lb)/4.5 kg (9.92 lb)
Certificate
  • CE, FCC class B, EN606011-1
EOS
  • Windows® 8.1, WE8S, Windows® 7, WES7
Mounting
  • VESA arm
  • Desktop stand
  • Wall mount

Ordering Information

  • MPC153-834-PCT-J
  • 15.6″ WXGA fanless medical touch panel computer with Intel® Celeron® processor J1900, projected capactive multi-touch screen, AC-DC 60 W power adapter (screw type connector), EMI class B and EN 60601-1 certified
  • MPC153-834-FR-J
  • 15.6″ WXGA fanless medical touch panel computer with Intel® Celeron® processor J1900, 5-wire flat resistive touch screen, AC-DC 60 W power adapter (screw type connector), EMI class B and EN 60601-1 certified
  • MPC153-834-PCT-DC
  • 15.6″ WXGA fanless medical touch panel computer with Intel® Celeron® processor J1900, projected capactive multi-touch screen,10~30 VDC power input (terminal block connector) and EN 60601-1 certified
  • MPC153-834-FR-DC
  • 15.6″ WXGA fanless medical touch panel computer with Intel® Celeron® processor J1900, 5-wire flat resistive touch screen, 10~30 VDC power input (terminal block connector) and EN 60601-1 certified
